Applications and Implications
Placeholder poster
video clip (presentation.mp4, 1080p HTML5, < ~minute, < ~25 MB),
What will it do?
This humidifier will activate if the humidity in the room is below 50%. The humidifier is built up of multiple chambers containing different scents. Which scent is released depends on what time of day it is.
The scents will be based on Helga Schimits theory of Uchronia and research done with an EEG scanner attempting to determine how different natural oils affect adtivates and decreases activity in some parts of the brain.
My goal is to create a humidifier that works with the 7 phases of the body: The sleep phase, the wake up phase, the cognitive productivity phase, the nap phase, the physical productivity phase, the intutive phase and the sleepiness phase.
Who's done what beforehand?
Humidifiers are fairly common at the moment. I have so far not found one releasing different scents. The closest I came was this jellyfish humidifier I found on Alibaba.
Katya Diaz FabAcademy Humidifier
Kae Nagano FabAcademy FLO interactive fireplace
Elen Grigoryans FabAcademy page
What sources will you use?
Not sure what this means
What will you design?
I will design the base, some of the electronic components, the water containers and the casing for the water containers as well as write the code.
Bill of Material
| Part | Item | Qty | Price/piece | total price | Link |
|---|---|---|---|---|---|
| Electronics | Ultrasonic atomizers | 8 | |||
| Electronics | 8 Relay module | 1 | |||
| Electronics | Esp Wroom Dev 1 board | 1 | |||
| Electronics | Xiao Esp32 C3 | 1 | |||
| Electronics | Oled | 1 | |||
| Electronics | Bme280 humidity tensor | 1 | |||
| Filament | White | 1 | |||
| Wood | Plate 45 x 45 cm | 1 | |||
| Wood | 145 x 5 | 1 | |||
| Acrylic | 10 x 10 | 7 | |||
| PCB | Copper PCB board | 1 | |||
| Electronics | Screw terminals |
What parts and systems will be made?
Materials:
- PLA filament
- wood
- Acrylic sheet
Components:
- Relay module
- Ultrasonic atomizers
- Xiao Esp32 3C
- BME280 humidity and temperature sensor
- Xiao Esp32 S3
What processes will be used?
Processes:
- 3D printing
- Laser cutting
- CNC milling
- PCB milling and soldering
- Programming
What questions need to be answered?
How can I securely make a watertight container with 3D printing?
How will it be evaluated?
- Is it watertight?
- Does it disperse scent?
- Does the humidifier react to a timer and humidity values sent from the detection board on the wall?
Checklist
Your project should incorporate
2D and
3D design,
additive and
subtractive fabrication processes,
electronics design and
electronics production,
embedded microcontroller design,
interfacing, and
programming,
system integration and
packaging
Resourses
Esp32 bbuil board speedrun USB battery charger
Electronics
ESP32 Wroom 32E datasseet V1.2
Operating voltage/Power supply: 3.0 ~ 3.6 V
Capacative touch pins: GPIO32, GPIO33, GPIO37, GPIO14, GPIO12, GPIO13, GPIO15, GPIO02, GPIO0 and GPIO04
power supply: https://www.tinytronics.nl/nl/power/voedingen/5v/mean-well-voeding-5v-3a-switching-power-supply-rs-15-5
